Dynamic Handwritten Signature Verification Models Protection Method Based on Contrastive Learning

doi:10.3969/j.issn.1671-1122.2025.12.008

Abstract

Abstract:

Dynamic handwritten signatures, as an important means of identity verification, usually compare the signature template with the signature to be verified and determine its authenticity based on a threshold. However, with the wide application of deep learning in the verification of handwritten signatures, the scale of models and training costs have significantly increased. Moreover, when models are provided as services, they are at risk of being illegally invoked or abused. To ensure that the signature verification model was only used by authorized users, this paper proposed a dynamic handwritten signature model protection method based on contrastive learning. This method jointly optimized the key embedding and signature verification model by constructing the contrastive loss between the signature containing the correct key and the original signature, as well as between the signature containing the correct key and the signature containing the random key, so that the model only maintained the verification capability for the signature containing the correct key, thereby effectively preventing unauthorized access. Meanwhile, this mechanism could achieve the confirmation of model ownership and the tracking of intellectual property rights. The experimental results based on the large dynamic signature dataset DeepSignDB show that under the condition of having 4 signature templates and including skilled forgery samples, the equal error rate of signatures with correct keys increases from 2.65% of the original model to 4.40%, and the original signatures and signatures with random keys increase to 16.98% and 16.51% respectively. It has achieved a significant enhancement in model security and traceability while still maintaining the original signature verification performance.

Key words: dynamic handwritten signature verification, model protection, contrastive learning

CLC Number:

TP309

FU Zhangjie, CHEN Tianyu, CUI Qi. Dynamic Handwritten Signature Verification Models Protection Method Based on Contrastive Learning[J]. Netinfo Security, 2025, 25(12): 1927-1935.

Figures/Tables 9

References 39

[1]	LAI Songxuan. Signature Verification and Writer Identification Based on Deep Learning and Domain Knowledge[D]. Guangzhou: South China University of Technology, 2021.
	赖松轩. 基于深度学习与领域知识的签名认证与笔迹识别[D]. 广州: 华南理工大学, 2021.
[2]	QUAN Zhonghua. A Study of the Authentication Based on Online Signatures[D]. Hefei: University of Science and Technology of China, 2007.
	全中华. 基于动态手写签名的身份认证研究[D]. 合肥: 中国科学技术大学, 2007.
[3]	DIAZ M, FISCHER A, PLAMONDON R, et al. Towards an Automatic On-Line Signature Verifier Using Only One Reference Per Signer[C]// IEEE. 2015 13th International Conference on Document Analysis and Recognition (ICDAR). New York: IEEE, 2015: 631-635.
[4]	SAKOE H, CHIBA S. Dynamic Programming Algorithm Optimization for Spoken Word Recognition[J]. IEEE Transactions on Acoustics, Speech, and Signal Processing, 1978, 26(1): 43-49. doi: 10.1109/TASSP.1978.1163055 URL
[5]	YAN Chendan, YANG Yang, CHENG Jiujun, et al. A DTW Signature Verification System Based on Statistical Modeling[J]. Netinfo Security, 2015, 15(7): 64-70.
	鄢晨丹, 杨阳, 程久军, 等. 基于统计模型的DTW签名认证系统[J]. 信息网络安全, 2015, 15(7):64-70.
[6]	SANTOSH K C, WENDLING L. Character Recognition Based on Non-Linear Multi-Projection Profiles Measure[J]. Frontiers of Computer Science, 2015, 9(5): 678-690. doi: 10.1007/s11704-015-3400-2
[7]	LIU Yishu, YANG Zhihua, YANG Lihua. Online Signature Verification Based on DCT and Sparse Representation[J]. IEEE Transactions on Cybernetics, 2014, 45(11): 2498-2511. doi: 10.1109/TCYB.2014.2375959 URL
[8]	GALBALLY J, DIAZ-CABRERA M, FERRER M A, et al. On-Line Signature Recognition through the Combination of Real Dynamic Data and Synthetically Generated Static Data[J]. Pattern Recognition, 2015, 48(9): 2921-2934. doi: 10.1016/j.patcog.2015.03.019 URL
[9]	SHARMA A, SUNDARAM S. A Novel Online Signature Verification System Based on GMM Features in a DTW Framework[J]. IEEE Transactions on Information Forensics and Security, 2016, 12(3): 705-718. doi: 10.1109/TIFS.2016.2632063 URL
[10]	DIAZ M, FERRER M A, IMPEDOVO D, et al. A Perspective Analysis of Handwritten Signature Technology[J]. ACM Computing Surveys (CSUR), 2019, 51(6): 1-39.
[11]	LAI Songxuan, JIN Lianwen, ZHU Yecheng, et al. SynSig2Vec: Forgery-Free Learning of Dynamic Signature Representations by Sigma Lognormal-Based Synthesis and 1D CNN[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2021, 44(10): 6472-6485. doi: 10.1109/TPAMI.2021.3087619 URL
[12]	JIANG Jiajia, LAI Songxuan, JIN Lianmen, et al. DsDTW: Local Representation Learning with Deep Soft-Dtw for Dynamic Signature Verification[J]. IEEE Transactions on Information Forensics and Security, 2022, 17: 2198-2212. doi: 10.1109/TIFS.2022.3180219 URL
[13]	HASHIM Z, AHMED H M, ALKHAYYAT A H. A Comparative Study among Handwritten Signature Verification Methods Using Machine Learning Techniques[EB/OL]. (2022-10-15)[2025-09-30]. https://onlinelibrary.wiley.com/doi/full/10.1155/2022/8170424.
[14]	ZHOU Weilin, LIAO Zhimin, LI Ke, et al. The Construction of the “Internet + Cloud Signature” Public Service Cloud Platform[J]. Network Security Technology and Application, 2023(4): 58-61.
	周蔚林, 廖智敏, 李科, 等. “互联网+云签”公共服务云平台的建设[J]. 网络安全技术与应用, 2023(4):58-61.
[15]	JIN Biao, LIN Xiang, XIONG Jinbo, et al. Intellectual Property Protection of Deep Neural Network Models Based on Watermarking Technology[J]. Journal of Computer Research and Development, 2024, 61(10): 2587-2606.
	金彪, 林翔, 熊金波, 等. 基于水印技术的深度神经网络模型知识产权保护[J]. 计算机研究与发展, 2024, 61(10):2587-2606.
[16]	NAMBA R, SAKUMA J. Robust Watermarking of Neural Network with Exponential Weighting[C]// ACM. The 2019 ACM Asia Conference on Computer and Communications Security. New York: ACM, 2019: 228-240.
[17]	ZHENG Yue, WANG Si, CHANG C H. A DNN Fingerprint for Non-Repudiable Model Ownership Identification and Piracy Detection[J]. IEEE Transactions on Information Forensics and Security, 2022, 17: 2977-2989. doi: 10.1109/TIFS.2022.3198267 URL
[18]	DIAZ M, FERRER M A, ESKANDER G S, et al. Generation of Duplicated Off-Line Signature Images for Verification Systems[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2016, 39(5): 951-964. doi: 10.1109/TPAMI.2016.2560810 URL
[19]	TOLOSANA R, VERA-RODRIGUEZ R, FIERREZ J, et al. DeepSign: Deep On-Line Signature Verification[J]. IEEE Transactions on Biometrics, Behavior, and Identity Science, 2021, 3(2): 229-239. doi: 10.1109/TBIOM.2021.3054533 URL
[20]	TOLOSANA R, VERA-RODRIGUEZ R, GONZALEZ-GARCIA C, et al. SVC-onGoing: Signature Verification Competition[EB/OL]. (2022-02-24)[2025-09-30]. https://www.sciencedirect.com/science/article/pii/S0031320322000905.
[21]	SHEN Qi, LUAN Fangjun, YUAN Shuai. Multi-Scale Residual Based Siamese Neural Network for Writer-Independent Online Signature Verification[J]. Applied Intelligence, 2022, 52(12): 14571-14589. doi: 10.1007/s10489-022-03318-5
[22]	WU Xiaomeng, KIMURA A, KASHINO K, et al. Total Whitening for Online Signature Verification Based on Deep Representation[C]// IEEE. 2020 25th International Conference on Pattern Recognition (ICPR). New York: IEEE, 2021: 655-661.
[23]	VORUGUNTI C S, PULABAIGARI V, GORTHI R K S S, et al. Osvfusenet: Online Signature Verification by Feature Fusion and Depth-Wise Separable Convolution Based Deep Learning[J]. Neurocomputing, 2020, 409: 157-172. doi: 10.1016/j.neucom.2020.05.072 URL
[24]	FAN Xuefeng, ZHOU Xiaoyi, ZHU Bingbing, et al. Survey of Copyright Protection Schemes Based on DNN Model[J]. Journal of Computer Research and Development, 2022, 59(5): 953-977.
	樊雪峰, 周晓谊, 朱冰冰, 等. 深度神经网络模型版权保护方案综述[J]. 计算机研究与发展, 2022, 59(5)953-977.
[25]	JIN Song, WANG Yuhang. On Protecting Neural Network Model in Memristor Platforms[J]. Chinese Journal of Computers, 2022, 45(11): 2377-2392.
	靳松, 汪宇航. 一种面向忆阻器平台的神经网络模型保护方法[J]. 计算机学报, 2022, 45(11):2377-2392.
[26]	GUO Jingjing, LIU Jiuzun, MA Yong, et al. Backdoor Attack Defense Method for Federated Learning Based on Model Watermarking[J]. Chinese Journal of Computers, 2024, 47(3): 662-676.
	郭晶晶, 刘玖樽, 马勇, 等. 基于模型水印的联邦学习后门攻击防御方法[J]. 计算机学报, 2024, 47(3):662-676.
[27]	PYONE A, MAUNG M, KIYA H. Training DNN Model with Secret Key for Model Protection[C]// IEEE. 2020 IEEE 9th Global Conference on Consumer Electronics (GCCE). New York: IEEE, 2020: 818-821.
[28]	XU Chaohui, CUI Qi, DONG Jinxin, et al. IDEA: An Inverse Domain Expert Adaptation Based Active DNN IP Protection Method[EB/OL]. (2024-09-29)[2025-09-30]. https://arxiv.org/html/2410.00059v1.
[29]	LI Peihao, HUANG Jie, WU Huaqing, et al. SecureNet: Proactive Intellectual Property Protection and Model Security Defense for DNNs Based on Backdoor Learning[EB/OL]. (2024-03-07)[2025-09-30]. https://doi.org/10.1016/j.neunet.2024.106199.
[30]	LIU Ziyu, ZHOU Tong, LUO Yukui, et al. TBNet: A Neural Architectural Defense Framework Facilitating DNN Model Protection in Trusted Execution Environments[C]// ACM. The 61st ACM/IEEE Design Automation Conference. New York: ACM, 2024: 1-6.
[31]	NIE Hewang, LU Songfeng, WU Junjun, et al. Deep Model Intellectual Property Protection with Compression-Resistant Model Watermarking[J]. IEEE Transactions on Artificial Intelligence, 2024, 5(7): 3362-3373. doi: 10.1109/TAI.2024.3351116 URL
[32]	FAN Lixin, NG K W, CHAN C S, et al. DeepIPR: Deep Neural Network Ownership Verification with Passports[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2021, 44(10): 6122-6139. doi: 10.1109/TPAMI.2021.3088846 URL
[33]	XUE Mingfu, WU Yinghao, ZHANG L Y, et al. SSAT: Active Authorization Control and User’s Fingerprint Tracking Framework for DNN IP Protection[J]. ACM Transactions on Multimedia Computing, Communications and Applications, 2024, 20(10): 1-24.
[34]	XIE Yingsha, MIN Rui, QIN Zeyu, et al. RoMa: A Robust Model Watermarking Scheme for Protecting IP in Diffusion Models[EB/OL]. (2025-07-01)[2025-09-30]. https://openreview.net/forum?id=TN1XsCahN7.
[35]	KONG Cong, XU Rui, CHEN Jiawei, et al. Protecting Copyright of Medical Pre-Trained Language Models: Training-Free Backdoor Model Watermarking[C]// ACM. The 33rd ACM International Conference on Multimedia. New York: ACM, 2025: 11590-11599.
[36]	ORTEGA-GARCIA J, FIERREZ-AGUILAR J, SIMON D, et al. MCYT Baseline Corpus: A Bimodal Biometric Database[J]. IEE Proceedings-Vision, Image and Signal Processing, 2003, 150(6): 395-401. doi: 10.1049/ip-vis:20031078 URL
[37]	FIERREZ J, GALBALLY J, ORTEGA-GARCIA J, et al. BiosecurID: A Multimodal Biometric Database[J]. Pattern Analysis and Applications, 2010, 13(2): 235-246. doi: 10.1007/s10044-009-0151-4 URL
[38]	ORTEGA-GARCIA J, FIERREZ-AGUILAR J, ALONSO-FERNANDEZ F, et al. The Multiscenario Multienvironment BioSecure Multimodal Database (BMDB)[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2009, 32(6): 1097-1111. doi: 10.1109/TPAMI.2009.76 URL
[39]	TOLOSANA R, VERA-RODRIGUEZ R, FIERREZ-AGUILAR J, et al. Benchmarking Desktop and Mobile Handwriting across COTS Devices: The E-BioSign Biometric Database[EB/OL]. (2017-05-05)[2025-09-30]. https://pmc.ncbi.nlm.nih.gov/articles/PMC5419513/.

数据集	模型	熟练伪造			随机伪造
数据集	模型	原始	正确密钥	随机密钥	原始	正确密钥	随机密钥
MCYT	未保护	4.06%	4.22%	3.99%	0.55%	0.51%	0.49%
MCYT	保护	30.07%	8.40%	19.55%	26.10%	2.87%	15.17%
BiosecurID	未保护	2.51%	2.76%	2.46%	0.65%	0.73%	0.91%
BiosecurID	保护	30.02%	6.51%	36.52%	28.46%	3.29%	31.45%
Biosecure DS2	未保护	4.96%	5.06%	5.04%	1.14%	1.28%	1.39%
Biosecure DS2	保护	32.55%	11.56%	27.76%	30.79%	5.69%	21.97%
e-BioSign DS2	未保护	4.35%	4.76%	4.58%	2.14%	2.31%	2.05%
e-BioSign DS2	保护	24.63%	7.62%	11.77%	23.87%	4.53%	12.05%
e-BioSign DS1	未保护	6.50%	6.60%	7.10%	1.99%	2.11%	2.01%
e-BioSign DS1	保护	27.62%	10.86%	12.42%	23.84%	4.41%	7.24%
DeepSignDB	未保护	4.42%	4.59%	4.49%	0.94%	0.96%	1.20%
DeepSignDB	保护	31.18%	9.52%	24.34%	28.04%	4.11%	20.45%

数据集	模型	熟练伪造			随机伪造
数据集	模型	原始	正确密钥	随机密钥	原始	正确密钥	随机密钥
MCYT	未保护	2.21%	2.54%	2.26%	0.21%	0.17%	0.19%
MCYT	保护	16.97%	3.26%	10.36%	12.52%	0.68%	6.17%
BiosecurID	未保护	1.26%	1.19%	1.19%	0.41%	0.31%	0.50%
BiosecurID	保护	15.48%	2.30%	28.79%	13.06%	0.75%	22.39%
Biosecure DS2	未保护	3.51%	4.05%	3.45%	1.35%	1.57%	1.66%
Biosecure DS2	保护	18.58%	6.07%	19.02%	14.53%	2.44%	11.54%
e-BioSign DS2	未保护	1.33%	1.42%	1.42%	0.71%	0.71%	0.71%
e-BioSign DS2	保护	13.19%	3.57%	8.09%	11.48%	2.14%	5.71%
e-BioSign DS1	未保护	3.21%	3.77%	3.49%	1.55%	1.49%	1.58%
e-BioSign DS1	保护	13.97%	5.71%	6.90%	10.24%	2.21%	3.38%
DeepSignDB	未保护	2.65%	2.99%	2.69%	0.74%	0.77%	0.86%
DeepSignDB	保护	16.98%	4.40%	16.51%	13.01%	1.45%	13.11%

模板数量/张	模型	熟练伪造			随机伪造
模板数量/张	模型	原始	正确密钥	随机密钥	原始	正确密钥	随机密钥
1	未保护	4.42%	4.59%	4.49%	0.94%	0.96%	1.20%
	保护一	37.88%	11.05%	25.46%	35.77%	5.01%	22.73%
	保护二	31.18%	9.52%	24.34%	28.04%	4.11%	20.45%
4	未保护	2.65%	2.99%	2.69%	0.74%	0.77%	0.86%
	保护一	22.78%	4.79%	16.86%	18.15%	1.61%	13.34%
	保护二	16.98%	4.40%	16.51%	13.01%	1.45%	13.11%

微调模型的密钥	访问密钥
微调模型的密钥	k₁	k₂	k₃	k₄	随机密钥
k₁	4.40%	14.69%	15.55%	19.31%	16.51%
k₂	13.47%	4.87%	8.60%	15.17%	11.97%
k₃	12.22%	16.57%	4.49%	17.89%	17.46%
k₄	14.55%	8.29%	10.77%	4.28%	13.10%

模板数量 /张	模型	熟练伪造			随机伪造
模板数量 /张	模型	原始	正确密钥	随机密钥	原始	正确密钥	随机密钥
1	DeepIPR	33.11%	20.16%	36.43%	28.59%	14.61%	34.54%
	SSAT	41.20%	17.35%	35.71%	36.85%	10.05%	33.53%
	本文方法	31.18%	9.52%	24.34%	28.04%	4.11%	20.45%
4	DeepIPR	18.78%	9.55%	29.66%	14.21%	6.07%	24.77%
	SSAT	25.82%	7.59%	27.30%	18.98%	3.72%	22.63%
	本文方法	16.98%	4.40%	16.51%	13.01%	1.45%	13.11%
